Linemods Stealth 209 Premium Inkjet/Dryer Base

Linemods equipment is designed with a balance of easy operation, longevity and innovation from over 25 years of experience in the post press/production environment – All equipment equipped with a 2-year built-in warranty.

Quality Without Compromise:

Linemods Premium Inkjet/Dryer Base - Quality without compromise, from the innovative vacuum system to the powder coated aluminum frames. Perform quick, easy setups – Linemods “Stealth” systems incorporate our patented “I Series” transport design.

​PROVIDES “WIDE BELT” THROUGHPUT AND EDGE CONSISTENCY – WITHOUT THE WIDEBELT COSTS

Attributes:

• .5mm belt height (from deck)
• Advanced auto-regulated vacuum system
• Premium silicone dryer belts
• 3/8” Powder coated aluminum frames
• Adj. height +5” (12.7cm) from casters
• Tool-less adjustments
• Integrated encoder mount
• Upstream/downstream, speed-following​

System Design & Details:

All Linemods “Stealth” units are performance engineered to deliver an optimum supply of vacuum without stalling conveyor or stressing pump – We use regenerative turbine vacuum system with pressure sensors to precisely control the vacuum pressure – Linemods offers the most innovative, high performance vacuum conveyor systems available.

Feature attributes:

• Touch-screen HMI
• 2 year warranty
• Simple electrical/drive components
• Minimal tools needed to perform most set-ups/changeovers
• Vacuum belt construction is of a friction resistant backer, perforated for vacuum integration – Timing belts provide skew free operation on the inkjet section
• Component design – All pivot points have bearings, all components designed to last

Product Capacity:

Width: Up to 21” (53cm)
Speed: 600 (183m) or optional 1000 (305m) LFPM

• Product thickness range:  .05mm - 13mm
• Product width range: 2” - 21”
• Gross weight: 595 lbs
• Electrical: 200-240v 1 Ph / 30amps ​
