UV Curable Print Solution

Mailing- Printing - Bindery - Packaging - Web -Newspaper

Addressing - Marking - Coding - Barcode - Labels - Polybags and More!

The high resolution iM2 and iM4 printers provides a versatile, cost-effective solution to meet the need for variable data printing on a range of coated and uncoated substrates. Capable of printing addresses, barcodes, 2D codes, QR codes, numbering, logos and graphics, the iM2 or the iM4 are suitable for mailing, packaging and addressing applications, as well as labels, tickets, security, plastic cards and business form applications.

The very small footprint and modular design of the iM2 or iM4 means that it is easily and quickly integrated into mailing lines, webs and card lines. With all the printer electronics and ink delivery systems built into the Printhead assembly, it is designed for maximum uptime.

UV Curable Print Solution

Now you can print on those difficult substrates  with a UV ink curable system. With a UV Inkjet system, you will be able to print on items such as un-coated and coated postcards, High gloss stocks, credit cards, poly bag, and more. (send us your samples for testing)

The high-resolution CME iM2 printer provides a versatile, cost-effective solution to meet the need for variable data printing on a range of coated and uncoated substrates. Capable of printing addresses, barcodes, 2D codes, QR codes, numbering, logos and graphics, the CME iM2 is suitable for mailing and addressing applications, as well as labels, tickets, security, plastic cards and business form applications. The very small footprint and modular design of the CME iM2 means that it is easily and quickly integrated into mailing lines, webs and card lines. With all the printer electronics and ink delivery systems built into the printhead assembly, it is designed for maximum uptime.

Compact Size

One of the key design mandates for the CME iM2 was a small footprint. Not only is the printhead compact, so is the interface enclosure. For the first time, trying to find space on your equipment for bulky ink handling systems and print heads is no longer a concern. Whatever available space you have, the CME iM2 can fit!

Groundbreaking Design

Simplicity is the key to the CME iM2 design. From the patented ink delivery system to the electronics, housing and interface connectors, the CME iM2 has been designed with ease of use in mind.

The CME iM2 uses a single pump and sensor to measure the ink pressure and to pump the ink directly from the supply to the print head as ink is being consumed while printing. Since there is no air reservoir for meniscus control there are no issues with ink flow, or flooding air sensors or valves (there are none).

With the head mounted directly to the manifold, the design greatly reduces the number of connections, tubes and failure points where leaks can occur.

The CME iM2 incorporates an integrated manifold heater that can preheat the ink before it reaches the head allowing the ink to flow better and operate much more reliably at higher speeds, resulting in less nozzle outs.

The head can be changed in the field without disassembling the ink delivery system and or any of the ink delivery connections. The system can be installed, primed and operational in less than 1 hour.

Software that Delivers

The iM2 has multiple capabilities regarding software. It ships with a standard GUI based upon the proven Inc.Jet software, or alternatively, it can be supplied with a set of tools to enable custom software development.

With the standard GUI, you can be up and running within minutes from design of the basic job template to hitting the Start button and being in production! Bring in databases and easily build a template that fully utilizes the power of dynamic text, bitmaps, counters and so much more. Insert Lot codes, expiry dates and any of over 100 different barcodes.

There are tens of thousands of solid high performing installations of this software installed globally, so there is never a fear of poorly developed software that doesn't have the flexibility and power you need. Proven repeatedly to perform.

The software is a proven enterprise level solution that will help you monitor, manage and maximize your print stream. And what's more, its completely free with eternal updates!

Applications

• Postcards
• Mail
• Packaging
• Bindery
• Newsprint
• Plastic Cards
• Folders
• Labels
• Tickets
• Tags
• Inserters
• Stitchers
• Poly Bags
• and more!
